Registre des plans & études — Barrage de Grand Katende
Détail plan par plan des livrables de conception soumis par Angelique International Ltd (AIL) au maître d'ouvrage GCK et au PMC Econergy, avec leur statut de validation.
279
plans référencés
279
soumis
0
approuvés
| N° de plan | Intitulé | Série | Soumis le | Statut |
|---|---|---|---|---|
| AFRY.0082.01.001 | INFRASTRUCTURE, TEMPORARY HOUSING AND GUEST HOUSE, GENERAL ARRANGEMENT, LAYOUT PLAN | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.002 | INFRASTRUCTURE, TEMPORARY HOUSING AND GUEST HOUSE, GENERAL ARRANGEMENT, PLAN & DETAILS | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.003 | INFRASTRUCTURE, TEMPORARY HOUSING AND GUEST HOUSE, GENERAL ARRANGEMENT, VIEW A & B | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.004 | INFRASTRUCTURE, TEMPORARY HOUSING AND GUEST HOUSE, GENERAL ARRANGEMENT, VIEW C & DETAILS | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.005 | INFRASTRUCTURE, TEMPORARY HOUSING AND GUEST HOUSE, GENERAL ARRANGEMENT, SECTION 1 – 1 & 2 – 2 | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.006 | INFRASTRUCTURE, KITCHEN & DINING ROOM FOR TEMPORARY GUEST HOUSE, GENERAL ARRANGEMENT, PLAN, VIEW A & DETAILS | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.007 | INFRASTRUCTURE, KITCHEN & DINING ROOM FOR TEMPORARY GUEST HOUSE, GENERAL ARRANGEMENT, PLAN, VIEW B, C & DETAILS | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.008 | INFRASTRUCTURE, KITCHEN & DINING ROOM FOR TEMPORARY GUEST HOUSE, GENERAL ARRANGEMENT, PLAN, SECTION 1 – 1, 2 – 2 & DETAILS | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.011 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE (8 ROOMS) KITCHEN WITH DINING HALL, GENERAL ARRANGEMENT, LAYOUT PLAN | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.012 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE, GENERAL ARRANGEMENT, PLAN & DETAILS | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.013 | INFRASTRUCTURE, SITE OFFICE BLOCK – I & II FOR CONTRACTOR, GENERAL ARRANGEMENT, VIEW A & B | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.014 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE, GENERAL ARRANGEMENT, VIEW C & DETAILS | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.015 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE, GENERAL ARRANGEMENT, SECTION 1 – 1 & 2 – 2 | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.016 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE KITCHEN WITH DINING HALL, GENERAL ARRANGEMENT, PLAN, VIEW A & DETAILS | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.017 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE KITCHEN WITH DINING HALL, GENERAL ARRANGEMENT, VIEW B, C & DETAILS | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.018 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE KITCHEN WITH DINING HALL, GENERAL ARRANGEMENT, SECTION 1 – 1, 2 – 2 & DETAILS | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.020 | INFRASTRUCTURE, SITE OFFICE BLOCK – I & II FOR CONTRACTOR, GENERAL ARRANGEMENT, LAYOUT PLAN | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.021 | INFRASTRUCTURE, SITE OFFICE BLOCK – I & II FOR CONTRACTOR, GENERAL ARRANGEMENT, PLAN | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.022 | INFRASTRUCTURE, SITE OFFICE BLOCK – I & II FOR CONTRACTOR, GENERAL ARRANGEMENT, VIEW A & B | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.023 | INFRASTRUCTURE, SITE OFFICE BLOCK – I & II FOR CONTRACTOR, GENERAL ARRANGEMENT, VIEW C & D | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.024 | INFRASTRUCTURE, SITE OFFICE BLOCK – I FOR CONTRACTOR, GENERAL ARRANGEMENT, SECTION 1 – 1 AND SECTION 2 – 2 | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.025 | INFRASTRUCTURE, SITE OFFICE BLOCK – I & II FOR CONTRACTOR, GENERAL ARRANGEMENT, , DETAILS | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.026 | INFRASTRUCTURE, SITE OFFICE BLOCK – II FOR CONTRACTOR, GENERAL ARRANGEMENT, PLAN | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.027 | INFRASTRUCTURE, SITE OFFICE BLOCK – II FOR CONTRACTOR, GENERAL ARRANGEMENT, VIEW A & B | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.028 | INFRASTRUCTURE, SITE OFFICE BLOCK – II FOR CONTRACTOR, GENERAL ARRANGEMENT, VIEW C & D | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.029 | INFRASTRUCTURE, SITE OFFICE BLOCK – II FOR CONTRACTOR, GENERAL ARRANGEMENT, SECTION 1 – 1 & SECTION 2 – 2 | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.031 | Infrastructure â Residential Accommodation Three Bedroom House – General Arrangement(Layout plan) | Infrastructure de chantier | 22 déc. 2025 | Soumis |
| AFRY.0082.01.032 | Infrastructure â Residential Accommodation Three Bedroom House – General Arrangement (Plan) | Infrastructure de chantier | 22 déc. 2025 | Soumis |
| AFRY.0082.01.033 | Infrastructure â Residential Accommodation Three Bedroom House – General Arrangement (View A, B & Details) | Infrastructure de chantier | 22 déc. 2025 | Soumis |
| AFRY.0082.01.034 | Infrastructure â Residential Accommodation Three Bedroom House – General Arrangement (View C, D & Details) | Infrastructure de chantier | 22 déc. 2025 | Soumis |
| AFRY.0082.01.035 | Infrastructure â Residential Accommodation Three Bedroom House – General Arrangement (Sections & Detail) | Infrastructure de chantier | 22 déc. 2025 | Soumis |
| AFRY.0082.01.036 | Infrastructure â Residential Accommodation Three Bedroom House – General Arrangement (Plinth Beam &Tie Beam Layout Plan) | Infrastructure de chantier | 22 déc. 2025 | Soumis |
| AFRY.0082.01.041 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, GENERAL ARRANGEMENT, LAYOUT PLAN | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.042 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, , GENERAL ARRANGEMENT, PLAN & DETAILS | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.043 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, , GENERAL ARRANGEMENT, VIEW A & B | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.044 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, GENERAL ARRANGEMENT, VIEW C & DETAILS | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.045 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, GENERAL ARRANGEMENT, SECTION 1 – 1 & 2 – 2 | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.046 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, , GENERAL ARRANGEMENT, PLAN, VIEW A & DETAILS | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.047 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, , GENERAL ARRANGEMENT, VIEW B, C & DETAILS | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.048 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, ARRANGEMENT, SECTION 1 – 1, 2 – 2 & DETAILS | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.051 | Infrastructure – – Labour/Workerâs Colony – General Arrangement – (Layout plan) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.052 | Infrastructure – Labour/Workerâs Colony – General Arrangement – (Plan) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.053 | Infrastructure – Labour/Workerâs Colony – General Arrangement – (View A & B) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.054 | Infrastructure – Labour/Workerâs Colony – General Arrangement â(View C & D) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.055 | Infrastructure – Labour/Workerâs Colony – General Arrangement – (Section 1 – 1 & 2 – 2) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.056 | Infrastructure – Labour/Workerâs Colony – General Arrangement – (Details) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.057 | Infrastructure – Kitchen & Dining Room for Labour/Workerâs Colony – General Arrangement – (Plan, View A & Details) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.058 | Infrastructure – Kitchen & Dining Room for Labour/Workerâs Colony – General Arrangement – (View B, C & Details) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.059 | Infrastructure – Kitchen & Dining Room for Labour/Workerâs Colony – General Arrangement – (Sections 1 – 1, 2 – 2 & Details) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.060 | Infrastructure – Bathroom & Toilets for Labour/Workerâs Colony – General Arrangement – (Plan, Section & Details) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.065 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 1) – General Arrangement – (Layout plan) | Infrastructure de chantier | 18 nov. 2025 | Soumis |
| AFRY.0082.01.066 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 1) – General Arrangement – (Plan, Section & Details) | Infrastructure de chantier | 18 nov. 2025 | Soumis |
| AFRY.0082.01.067 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 1) – General Arrangement – (View & Details) | Infrastructure de chantier | 18 nov. 2025 | Soumis |
| AFRY.0082.01.068 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 1) – General Arrangement â(Sections & Details) | Infrastructure de chantier | 18 nov. 2025 | Soumis |
| AFRY.0082.01.069 | Infrastructure Workshop – General Arrangement – (Layout plan) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.070 | Infrastructure Workshop – General Arrangement – (Plan & Details) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.071 | Infrastructure Workshop – General Arrangement – (View A, B & Details) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.072 | Infrastructure Workshop – General Arrangement – (View C, D, Section & Details) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.074 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 4) – General Arrangement – (Layout plan) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.075 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 4) – General Arrangement – (Plan & Details) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.076 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 4) – General Arrangement – (View A, B & Details) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.077 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 2) – General Arrangement – (Layout plan) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.078 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 2) – General Arrangement – (Plan & Details) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.079 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 2) – General Arrangement – (View & Section) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.080 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 2) – General Arrangement â(Sections & Details) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.085 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 5) – General Arrangement – (Layout plan) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.086 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 5) – General Arrangement – (Plan & View – A) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.087 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 5) – General Arrangement – (Section – 2 & Details) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.088 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 5) – General Arrangement â(View C, View D & Details) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.089 | Infrastructure Semi – Storage Shed – General Arrangement – (Layout plan) | Infrastructure de chantier | 27 nov. 2025 | Soumis |
| AFRY.0082.01.090 | Infrastructure Semi – Storage Shed – General Arrangement – (Plan, Section & Details) | Infrastructure de chantier | 27 nov. 2025 | Soumis |
| AFRY.0082.01.091 | Infrastructure Semi – Storage Shed – General Arrangement – (View, Section & Details) | Infrastructure de chantier | 27 nov. 2025 | Soumis |
| AFRY.0082.01.092 | Potable / Drinking Water System ( Water Storage Tank ) Concrete Outline Plan | Infrastructure de chantier | 02 déc. 2025 | Soumis |
| AFRY.0082.01.093 | Potable / Drinking Water System ( Water Storage Tank ) Concrete Outline Sections | Infrastructure de chantier | 02 déc. 2025 | Soumis |
| AFRY.0082.01.094 | Infrastructure â Medical Center – General Arrangement(Layout plan) | Infrastructure de chantier | 20 janv. 2026 | Soumis |
| AFRY.0082.01.095 | Infrastructure â Medical Center – General Arrangement (Plan) | Infrastructure de chantier | 20 janv. 2026 | Soumis |
| AFRY.0082.01.096 | Infrastructure â Medical Center – General Arrangement (View A & B ) | Infrastructure de chantier | 20 janv. 2026 | Soumis |
| AFRY.0082.01.097 | Infrastructure â Medical Center – General Arrangement (Section 1 – 1 & Details) | Infrastructure de chantier | 20 janv. 2026 | Soumis |
| AFRY.0082.01.098 | Infrastructure â Medical Center – General Arrangement (View C, D & Detail) | Infrastructure de chantier | 20 janv. 2026 | Soumis |
| AFRY.0082.01.099 | Infrastructure â Medical Center – General Arrangement (Section 2 – 2 & 3 – 3) | Infrastructure de chantier | 20 janv. 2026 | Soumis |
| AFRY.0082.01.101 | INFRASTRUCTURE, SECURITY HUT & LAVATORIES (6 NOS.), PLAN & SECTION | Infrastructure de chantier | 12 oct. 2025 | Soumis |
| AFRY.0082.01.105 | INFRASTRUCTURE, OPEN STORAGE AREA, GENERAL ARRANGEMENT TYPICAL PLAN, SECTION & DETAIL | Infrastructure de chantier | 05 janv. 2026 | Soumis |
| AFRY.0082.01.107 | INFRASTRUCTURE LABORATORY GENERAL ARRANGEMENT, PLAN, VIEW – B & VIEW – C | Infrastructure de chantier | 29 avr. 2026 | Soumis |
| AFRY.0082.01.108 | INFRASTRUCTURE LABORATORY GENERAL ARRANGEMENT, VIEW – A & DETAILS | Infrastructure de chantier | 29 avr. 2026 | Soumis |
| AFRY.0082.01.109 | INFRASTRUCTURE LABORATORY GENERAL ARRANGEMENT, PLINTH BEAM & TIE BEAM LAYOUT PLAN | Infrastructure de chantier | 29 avr. 2026 | Soumis |
| AFRY.0082.01.401 | INFRASTRUCTURE, TEMPORARY HOUSING AND GUEST HOUSE, REINFORCEMENT, TYPICAL BEAM DETAILS & SECTIONS | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.402 | INFRASTRUCTURE, TEMPORARY HOUSING AND GUEST HOUSE, GENERAL ARRANGEMENT, TYPICAL COLUMN DETAILS & SECTIONS | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.403 | INFRASTRUCTURE, TEMPORARY HOUSING AND GUEST HOUSE, GENERAL ARRANGEMENT, TYPICAL BEAM DETAILS & SECTIONS | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.404 | INFRASTRUCTURE, KITCHEN & DINING ROOM FOR TEMPERORY GUEST HOUSE, GENERAL ARRANGEMENT, , TYPICAL COLUMN DETAILS & SECTIONS | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.411 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE, REINFORCEMENT, TYPICAL BEAM DETAILS & SECTIONS | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.412 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE, REINFORCEMENT, TYPICAL COLUMN DETAILS & SECTIONS | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.413 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE KITCHEN WITH DINING HALL, REINFORCEMENT, TYPICAL BEAM DETAILS & SECTIONS | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.414 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE KITCHEN WITH DINING HALL, REINFORCEMENT, TYPICAL COLUMN DETAILS & SECTIONS | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.421 | INFRASTRUCTURE, SITE OFFICE BLOCK – I & II FOR CONTRACTOR, REINFORCEMENT, TYPICAL BEAM DETAILS & SECTIONS | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.422 | INFRASTRUCTURE, SITE OFFICE BLOCK – I & II FOR CONTRACTOR, REINFORCEMENT, TYPICAL COLUMN, BEAM DETAILS & SECTIONS | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.441 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, REINFORCEMENT, TYPICAL BEAM DETAILS & SECTIONS | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.442 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, REINFORCEMENT, TYPICAL COLUMN DETAILS & SECTIONS | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.443 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, KITCHEN WITH DINING HALL, REINFORCEMENT, TYPICAL BEAM DETAILS & SECTIONS | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.444 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, KITCHEN WITH DINING HALL, REINFORCEMENT, TYPICAL COLUMN DETAILS & SECTIONS | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.451 | Infrastructure – Labour/Workerâs Colony – Reinforcement – (Typical Beam Details & Sections) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.452 | Infrastructure – Labour/Workerâs Colony – Reinforcement – (Typical Column Details & Sections) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.453 | Infrastructure – Kitchen & Dining Room for Labour/Workerâs Colony – Reinforcement – (Typical Beam Details & Sections) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.454 | Infrastructure – Kitchen & Dining Room for Labour/Workerâs Colony – Reinforcement – (Typical Column Details & Sections) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.463 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 1) – Reinforcement – (Typical Column Details & Sections) | Infrastructure de chantier | 18 nov. 2025 | Soumis |
| AFRY.0082.01.464 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 1) – Reinforcement – (Typical Column, Beam Details & Sections) | Infrastructure de chantier | 18 nov. 2025 | Soumis |
| AFRY.0082.01.465 | Reinforcement Potable / Drinking Water System ( Water Storage Tank ) Plan | Infrastructure de chantier | 02 déc. 2025 | Soumis |
| AFRY.0082.01.466 | Reinforcement Potable / Drinking Water System ( Water Storage Tank ) Plan B & Section | Infrastructure de chantier | 02 déc. 2025 | Soumis |
| AFRY.0082.01.467 | Reinforcement Potable / Drinking Water System ( Water Storage Tank ) Column, Beam & Sections | Infrastructure de chantier | 02 déc. 2025 | Soumis |
| AFRY.0082.01.468 | RCC Staircase Drawing for PotableDrinking Water System(Water Storage Tank) | Infrastructure de chantier | 17 déc. 2025 | Soumis |
| AFRY.0082.01.496 | INFRASTRUCTURE LABORATORY REINFORCEMENT, TYPICAL COLUMN, BEAM DETAILS & SECTIONS | Infrastructure de chantier | 29 avr. 2026 | Soumis |
| AFRY.0082.01.601 | INFRASTRUCTURE, TEMPORARY HOUSING AND GUEST HOUSE, GENERAL ARRANGEMENT, STEEL STRUCTURE, PLAN | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.602 | INFRASTRUCTURE, TEMPORARY HOUSING AND GUEST HOUSE, GENERAL ARRANGEMENT, STEEL STRUCTURE, SECTIONS AND DETAILS | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.603 | INFRASTRUCTURE, KITCHEN & DINING ROOM FOR TEMPERORY GUEST HOUSE, GENERAL ARRANGEMENT, STEEL STRUCTURE, PLAN | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.604 | INFRASTRUCTURE, KITCHEN & DINING ROOM FOR TEMPERORY GUEST HOUSE, GENERAL ARRANGEMENT, SECTIONS AND DETAILS | Infrastructure de chantier | 18 sept. 2025 | Soumis |
| AFRY.0082.01.605 | INFRASTRUCTURE, SITE OFFICE BLOCK – I & II FOR CONTRACTOR, REINFORCEMENT, STEEL STRUCTURE, PLAN | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.606 | INFRASTRUCTURE, SITE OFFICE BLOCK – I & II FOR CONTRACTOR, REINFORCEMENT, STEEL STRUCTURE, SECTIONS AND DETAILS | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.607 | INFRASTRUCTURE, SITE OFFICE BLOCK – I & II FOR CONTRACTOR, REINFORCEMENT, STEEL STRUCTURE, SECTIONS AND DETAILS | Infrastructure de chantier | 23 sept. 2025 | Soumis |
| AFRY.0082.01.611 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE STEEL STRUCTURE, GENERAL ARRANGEMENT, PLAN | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.612 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE STEEL STRUCTURE, GENERAL ARRANGEMENT, SECTIONS AND DETAILS | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.613 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE KITCHEN WITH DINING, STEEL STRUCTURE, GENERAL ARRANGEMENT, PLAN | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.614 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION GUEST HOUSE KITCHEN WITH DINING, STEEL STRUCTURE, GENERAL ARRANGEMENT, SECTIONS AND DETAILS | Infrastructure de chantier | 09 oct. 2025 | Soumis |
| AFRY.0082.01.615 | Infrastructure – Labour/Workerâs Colony – Steel Structure General Arrangement(Plan) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.616 | Infrastructure – Labour/Workerâs Colony – Steel Structure General Arrangement(Plan) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.617 | Infrastructure – Labour/Workerâs Colony – Steel Structure – General Arrangement (Section and Details) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.618 | Infrastructure – Labour/Workerâs Colony – Steel Structure – General Arrangement (Section and Details) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.619 | Infrastructure – Kitchen & Dining Room for Labour/Workerâs Colony – Steel Structure – General Arrangement – (Plan) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.620 | Infrastructure – Kitchen & Dining Room for Labour/Workerâs Colony – Steel Structure – General Arrangement – ( Section and Details) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.621 | Infrastructure – Bathrooms & Toilets for Labour/Workerâs Colony – Steel Structure – General Arrangement – (Plan) | Infrastructure de chantier | 06 nov. 2025 | Soumis |
| AFRY.0082.01.622 | Infrastructure â Residential Accommodation Three Bedroom House – Steel Structure – General Arrangement(Plan, Sections & Details) | Infrastructure de chantier | 22 déc. 2025 | Soumis |
| AFRY.0082.01.623 | Infrastructure â Residential Accommodation Three Bedroom House – Steel Structure – General Arrangement(Plan, Sections & Details) | Infrastructure de chantier | 22 déc. 2025 | Soumis |
| AFRY.0082.01.624 | Infrastructure â Residential Accommodation Three Bedroom House – Steel Structure – General Arrangement (Sections) | Infrastructure de chantier | 22 déc. 2025 | Soumis |
| AFRY.0082.01.625 | Infrastructure â Residential Accommodation Three Bedroom House – Steel Structure – General Arrangement (Sections & Details) | Infrastructure de chantier | 22 déc. 2025 | Soumis |
| AFRY.0082.01.626 | Infrastructure â Residential Accommodation Three Bedroom House – Steel Structure – General Arrangement (Sections & Details) | Infrastructure de chantier | 22 déc. 2025 | Soumis |
| AFRY.0082.01.633 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 1) – Steel Structure – General Arrangement(Plan) | Infrastructure de chantier | 18 nov. 2025 | Soumis |
| AFRY.0082.01.634 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 1) – Steel Structure – General Arrangement (Section and Details) | Infrastructure de chantier | 18 nov. 2025 | Soumis |
| AFRY.0082.01.635 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 1) – Steel Structure – General Arrangement (Elevations & Details) | Infrastructure de chantier | 18 nov. 2025 | Soumis |
| AFRY.0082.01.636 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 1) – Steel Structure – General Arrangement (Gable End View and Details) | Infrastructure de chantier | 18 nov. 2025 | Soumis |
| AFRY.0082.01.637 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 1) – Steel Structure – General Arrangement (Gable End View and Details) | Infrastructure de chantier | 18 nov. 2025 | Soumis |
| AFRY.0082.01.641 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, STEEL STRUCTURE, GENERAL ARRANGEMENT, PLAN | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.642 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, STEEL STRUCTURE, GENERAL ARRANGEMENT, SECTIONS AND DETAILS | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.643 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, KITCHEN WITH DINING HALL, STEEL STRUCTURE, GENERAL ARRANGEMENT, PLAN | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.644 | INFRASTRUCTURE, RESIDENTIAL ACCOMMODATION BLOCK – I, KITCHEN WITH DINING HALL, STEEL STRUCTURE, GENERAL ARRANGEMENT, SECTIONS AND DETAILS | Infrastructure de chantier | 30 sept. 2025 | Soumis |
| AFRY.0082.01.645 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 4) – General Arrangement â(View C, View D, Section & Details) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.646 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 4) – Steel Structure – General Arrangement(Plans & Elevations) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.647 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 4) – Steel Structure – General Arrangement (Section and Details) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.648 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 4) – Steel Structure – General Arrangement (Gable End View and Section) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.649 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 4) – Steel Structure – General Arrangement (Gable End View and Section) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.650 | Infrastructure Workshop – Steel Structure – General Arrangement(Elevations) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.651 | Infrastructure Workshop – Steel Structure – General Arrangement(Section & Details) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.652 | Infrastructure Workshop – Steel Structure – General Arrangement(Gable End View & Section) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.653 | Infrastructure Workshop – Steel Structure – General Arrangement(Gable End View & Details) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.654 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 2) – Steel Structure – General Arrangement(Plan & Elevations) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.655 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 2) – Steel Structure – General Arrangement (Section and Details) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.656 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 2) – Steel Structure – General Arrangement (Gable End View and Section) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.657 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 2) – Steel Structure – General Arrangement (Gable End View and Details) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.658 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 2) – Steel Structure – General Arrangement (Gable End View and Details) | Infrastructure de chantier | 25 nov. 2025 | Soumis |
| AFRY.0082.01.662 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 5) – Steel Structure – General Arrangement(Plans & Elevations) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.663 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 5) – Steel Structure – General Arrangement (Section and Details) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.664 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 5) – Steel Structure – General Arrangement (Gable End View and Section) | Infrastructure de chantier | 20 nov. 2025 | Soumis |
| AFRY.0082.01.665 | Infrastructure – Facilities for Civil & Hydro Mechanical Works (Store Block – 5) – Steel Structure – General Arrangement (Gable End View and Section) | Infrastructure de chantier | 17 déc. 2025 | Soumis |
| AFRY.0082.01.666 | Infrastructure Semi – Storage Shed – Steel Structure – General Arrangement(Plan & Details) | Infrastructure de chantier | 27 nov. 2025 | Soumis |
| AFRY.0082.01.667 | Infrastructure Semi – Storage Shed – Steel Structure – General Arrangement(Elevations, Section & Details) | Infrastructure de chantier | 27 nov. 2025 | Soumis |
| AFRY.0082.01.668 | Infrastructure Semi – Storage Shed – Steel Structure – General Arrangement(Section & Details) | Infrastructure de chantier | 27 nov. 2025 | Soumis |
| AFRY.0082.01.669 | Infrastructure Semi – Storage Shed – Steel Structure – General Arrangement(Gable End View) | Infrastructure de chantier | 27 nov. 2025 | Soumis |
| AFRY.0082.01.670 | Infrastructure â Medical Center – Steel Structure – General Arrangement(Plan) | Infrastructure de chantier | 20 janv. 2026 | Soumis |
| AFRY.0082.01.671 | Infrastructure â Medical Center – Steel Structure – General Arrangement(Plan & Sections) | Infrastructure de chantier | 20 janv. 2026 | Soumis |
| AFRY.0082.01.672 | Infrastructure â Medical Center – Steel Structure – General Arrangement (Sections & Details) | Infrastructure de chantier | 20 janv. 2026 | Soumis |
| AFRY.0082.02.001 | RIVER DIVERSION WORKS, COFFER DAM PHASE – I, GENERAL ARRANGEMENT, PLAN | Ouvrages hydrauliques & génie civil | 20 août 2025 | Soumis |
| AFRY.0082.02.002 | RIVER DIVERSION WORKS, COFFER DAM PHASE – I, GENERAL ARRANGEMENT, LONGITUDINAL SECTION | Ouvrages hydrauliques & génie civil | 20 août 2025 | Soumis |
| AFRY.0082.02.003 | RIVER DIVERSION WORKS, COFFER DAM PHASE – I, GENERAL ARRANGEMENT, SECTION 1 – 1 & 2 – 2 | Ouvrages hydrauliques & génie civil | 20 août 2025 | Soumis |
| AFRY.0082.02.004 | RIVER DIVERSION WORKS, COFFER DAM PHASE – II, GENERAL ARRANGEMENT, PLAN | Ouvrages hydrauliques & génie civil | 20 août 2025 | Soumis |
| AFRY.0082.02.005 | RIVER DIVERSION WORKS, COFFER DAM PHASE – II, GENERAL ARRANGEMENT, LONGITUDINAL SECTION & CROSS SECTIONS | Ouvrages hydrauliques & génie civil | 20 août 2025 | Soumis |
| AFRY.0082.02.006 | RIVER DIVERSION WORKS, TAILRACE CHANNEL, COFFER DAM, GENERAL ARRANGEMENT, PLAN | Ouvrages hydrauliques & génie civil | 10 sept. 2025 | Soumis |
| AFRY.0082.02.007 | RIVER DIVERSION WORKS, TAILRACE CHANNEL, COFFER DAM, GENERAL ARRANGEMENT, LONGITUDINAL SECTION | Ouvrages hydrauliques & génie civil | 10 sept. 2025 | Soumis |
| AFRY.0082.03.001 | DIVERSION WEIR GENERAL ARRANGEMENT, PLAN | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.03.002 | DIVERSION WEIR GENERAL ARRANGEMENT, SECTION 1 – 1 | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.03.003 | DIVERSION WEIR, SECTION 2 – 2 | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.03.004 | DIVERSION WEIR, SECTION 3 – 3 | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.03.005 | DIVERSION WEIR, SECTION 4 – 4 | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.03.006 | DIVERSION WEIR, SECTION 5 – 5 | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.03.101 | DIVERSION WEIR EXCAVATION, PLAN | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.03.102 | DIVERSION WEIR EXCAVATION, LONGITUDINAL SECTION, SECTION 1 – 1 | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.03.103 | DIVERSION WEIR EXCAVATION, LONGITUDINAL CROSS SECTION 2 – 2 | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.03.104 | DIVERSION WEIR EXCAVATION, LONGITUDINAL SECTION, SECTION 3 – 3 | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.03.105 | DIVERSION WEIR EXCAVATION, LONGITUDINAL SECTION, SECTION 4 – 2 | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.03.106 | DIVERSION WEIR EXCAVATION, LONGITUDINAL SECTION, SECTION 5 – 5 | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.03.301 | DIVERSION WEIR CONCRETE OUTLINE PLAN | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.03.302 | DIVERSION WEIR CONCRETE LONGITUDINAL SECTION SECTION 1 – 1 | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.03.303 | DIVERSION WEIR CONCRETE TYPICAL SECTIONS & DETAILS | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.03.304 | DIVERSION WEIR CONCRETE WATER STOP DETAILS, SECTIONS & DETAILS | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.03.305 | DIVERSION WEIR CONCRETE GUIDE WALL, PLAN & LONGITUDINAL SECTION | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.03.401 | DIVERSION WEIR REINFORCEMENT DETAILS, TYPICAL SECTIONS & DETAIL | Ouvrages hydrauliques & génie civil | 19 mars 2026 | Soumis |
| AFRY.0082.04.101 | Inlet Structure Excavation – Plan | Ouvrages hydrauliques & génie civil | 14 janv. 2026 | Soumis |
| AFRY.0082.04.102 | Inlet Structure Excavation âSection 1 – 1 | Ouvrages hydrauliques & génie civil | 14 janv. 2026 | Soumis |
| AFRY.0082.04.103 | Inlet Structure Excavation – Plan & Section 1 – 1 | Ouvrages hydrauliques & génie civil | 14 janv. 2026 | Soumis |
| AFRY.0082.04.104 | Inlet Structure Excavation – Section 2 – 2 & 3 – 3 | Ouvrages hydrauliques & génie civil | 14 janv. 2026 | Soumis |
| AFRY.0082.04.301 | Inlet Structure Concrete Outline Plan At EL. .00 | Ouvrages hydrauliques & génie civil | 16 févr. 2026 | Soumis |
| AFRY.0082.04.302 | Inlet Structure Concrete Outline Plan & Details At EL. .50 | Ouvrages hydrauliques & génie civil | 16 févr. 2026 | Soumis |
| AFRY.0082.04.303 | Inlet Structure Concrete Outline L – Section & Details | Ouvrages hydrauliques & génie civil | 16 févr. 2026 | Soumis |
| AFRY.0082.04.304 | Inlet Structure Concrete Outline Cross Sections & Details | Ouvrages hydrauliques & génie civil | 16 févr. 2026 | Soumis |
| AFRY.0082.04.401 | Inlet Structure Reinforcement Details Plan At EL. .00 & .50 | Ouvrages hydrauliques & génie civil | 16 févr. 2026 | Soumis |
| AFRY.0082.04.402 | Inlet Structure Reinforcement Details Section 1 – 1 & 2 – 2 | Ouvrages hydrauliques & génie civil | 16 févr. 2026 | Soumis |
| AFRY.0082.04.403 | Inlet Structure Reinforcement Details Sections & Beam Details | Ouvrages hydrauliques & génie civil | 16 févr. 2026 | Soumis |
| AFRY.0082.04.404 | Inlet Structure Reinforcement Details Abutment – 1, Pier – 1, Pier – 2 & Sections | Ouvrages hydrauliques & génie civil | 16 févr. 2026 | Soumis |
| AFRY.0082.05.001 | POWER CHANNEL GENERAL ARRANGEMENT, LAYPUT PLAN Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.002 | POWER CHANNEL GENERAL ARRANGEMENT, LONGITUDINAL SECTION OF POWER CHANNEL ALONG CENTER LINE, SECTION 1 – 1 & 2 – 2 | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.101 | Power Channel Excavation – Plan | Ouvrages hydrauliques & génie civil | 15 janv. 2026 | Soumis |
| AFRY.0082.05.102 | Power Channel Excavation â Longitudinal Section | Ouvrages hydrauliques & génie civil | 15 janv. 2026 | Soumis |
| AFRY.0082.05.103 | Power Channel Excavation – Cross Section 1 – 1 To 3 – 3 | Ouvrages hydrauliques & génie civil | 15 janv. 2026 | Soumis |
| AFRY.0082.05.104 | Power Channel Excavation – Cross Section 4 – 4 To 6 – 6 | Ouvrages hydrauliques & génie civil | 15 janv. 2026 | Soumis |
| AFRY.0082.05.105 | Power Channel Excavation – Cross Section 7 – 7 To 8 – 8 | Ouvrages hydrauliques & génie civil | 15 janv. 2026 | Soumis |
| AFRY.0082.05.301 | POWER CHANNEL, BACKFILL & LEVELING CONCRETE TYPICAL DETAILS, PLAN & SECTION | Ouvrages hydrauliques & génie civil | 10 sept. 2025 | Soumis |
| AFRY.0082.05.302 | POWER CHANNEL SIDE WALL & BED LINING DETAILS, CONCRETE OUTLINE – PLAN Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.303 | POWER CHANNEL, SIDE WALLS & BED LINING DETAILS, CONCRETE OUTLINE, LONGITUDINAL SECTION ALONG LEFT BANK WALL | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.304 | POWER CHANNEL, SIDE WALLS & BED LINING DETAILS, CONCRETE OUTLINE, LONGITUDINAL SECTION ALONG RIGHT BANK WALL | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.305 | POWER CHANNEL, SIDE WALLS & BED LINING DETAILS, CONCRETE OUTLINE, LONGITUDINAL SECTION OF POWER CHANNEL ALONG CENTER LINE | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.306 | POWER CHANNEL, SIDE WALLS & BED LINING DETAILS, CONCRETE OUTLINE, SECTION 1 – 1 & DETAILS Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.307 | POWER CHANNEL, SIDE WALLS & BED LINING DETAILS, CONCRETE OUTLINE, SECTION 2 – 2 & DETAILS Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.308 | POWER CHANNEL RETAINING WALL (GRAVITY) CONCRETE OUTLINE PLAN, SECTION & DETAILS Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.309 | POWER CHANNEL COUNTER FORT RETAINING WALL CF1 & CF2 CONCRETE OUTLINE, PLAN & SECTION Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.310 | POWER CHANNEL COUNTERFORT RETANING WALL CF3, CONCRETE OUTLINE, PLAN & SECTION Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.311 | POWER CHANNEL RAMP & RETANING WALL, CONCRETE OUTLINE, PLAN Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.312 | POWER CHANNEL RAMP & RETANING WALL, CONCRETE OUTLINE, LONGITUDINAL SECTION Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.313 | POWER CHANNEL RAMP & RETANING WALL, CONCRETE OUTLINE, SECTIONS Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.314 | POWER CHANNEL RAMP & RETANING WALL, CONCRETE OUTLINE, CROSS SECTION 3 – 3 & DETAILS Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.401 | POWER CHANNEL COUNTERFORT WALL (CF1) REINFORCEMENT DETAIL, PLAN, SECTIONS & DETAILS Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.402 | POWER CHANNEL COUNTERFORT WALL (CF2) REINFORCEMENT DETAIL, PLAN, SECTIONS & DETAILS Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.05.403 | POWER CHANNEL COUNTERFORT WALL (CF3) REINFORCEMENT DETAIL, PLAN, SECTIONS & DETAILS Submitted on Dated | Ouvrages hydrauliques & génie civil | 23 janv. 2026 | Soumis |
| AFRY.0082.06.001 | POWER INTAKE GENERAL ARRANGEMENT – PLAN | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.002 | POWER INTAKE GENERAL ARRANGEMENT – LONGITUDINAL SECTION ALONG POWER INTAKE – SECTION 1 – 1 | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.003 | POWER INTAKE GENERAL ARRANGEMENT – UPSTREAM VIEW | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.301 | POWER INTAKE CONCRETE OUTLINE – PLAN AT EL. .50, SECTION 4 – 4 & DETAILS | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.302 | POWER INTAKE CONCRETE OUTLINE – PLAN AT EL. .50 & SECTION 5 – 5 | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.303 | POWER INTAKE CONCRETE OUTLINE – PLAN AT EL. .94 | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.304 | POWER INTAKE CONCRETE OUTLINE – SECTION 1 – 1 & DETAILS | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.305 | POWER INTAKE CONCRETE OUTLINE – SECTION 2 – 2, & DETAILS | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.306 | POWER INTAKE CONCRETE OUTLINE – SECTION 3 – 3, 6 – 6, 7 – 7 & DETAIL | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.401 | POWER INTAKE REINFORCEMENT DETAIL PLAN AT EL. .50 & DETAILS | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.402 | POWER INTAKE REINFORCEMENT DETAIL PLAN AT EL. .50 & DETAILS | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.403 | POWER INTAKE REINFORCEMENT DETAIL – PLAN AT EL. .94 & DETAILS | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.404 | POWER INTAKE REINFORCEMENT DETAIL – SECTION 1 – 1 & DETAILS | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.405 | POWER INTAKE REINFORCEMENT DETAIL – SECTION 2 – 2, 3 – 3 & DETAIL | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.406 | POWER INTAKE REINFORCEMENT DETAIL – ABUTMENT PLAN & SECTION 1A – 1A & 1B – 1B | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.407 | POWER INTAKE REINFORCEMENT DETAIL – MIDDLE PIER PLAN & SECTION 2A – 2A & 2B – 2B | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.06.408 | POWER INTAKE REINFORCEMENT DETAIL – END PIER PLAN & SECTION 3A – 3A & 3B – 3B | Ouvrages hydrauliques & génie civil | 17 mars 2026 | Soumis |
| AFRY.0082.08.002 | POWER HOUSE EXCAVATION DETAIL – PLAN | Ouvrages hydrauliques & génie civil | 27 mars 2026 | Soumis |
| AFRY.0082.08.003 | POWER HOUSE EXCAVATION DETAIL – SECTION 1 – 1 & 2 – 2 | Ouvrages hydrauliques & génie civil | 27 mars 2026 | Soumis |
| AFRY.0082.08.004 | POWER HOUSE EXCAVATION DETAIL – SECTION 3 – 3 & 4 – 4 | Ouvrages hydrauliques & génie civil | 27 mars 2026 | Soumis |
| AFRY.0082.08.005 | POWER HOUSE EXCAVATION DETAIL – SECTION 5 – 5, 6 – 6 & 10 – 10 | Ouvrages hydrauliques & génie civil | 27 mars 2026 | Soumis |
| AFRY.0082.08.006 | POWER HOUSE EXCAVATION DETAIL – SECTION 7 – 7, 8 – 8 & 9 – 9 | Ouvrages hydrauliques & génie civil | 27 mars 2026 | Soumis |
| AFRY.0082.08.301 | POWER HOUSE COMPLEX.SERVICE BAY FLOOR, CONCRETE OUTLINE, PLAN AT EL. .00 & DETAIL Submitted on Dated | Ouvrages hydrauliques & génie civil | 31 juil. 2026 | Soumis |
| AFRY.0082.08.302 | POWER HOUSE COMPLEX.SERVICE BAY FLOOR, CONCRETE OUTLINE, PLAN AT EL. .00 Submitted on Dated | Ouvrages hydrauliques & génie civil | 31 juil. 2026 | Soumis |
| AFRY.0082.08.303 | POWER HOUSE COMPLEX.SERVICE BAY FLOOR, CONCRETE OUTLINE, SECTION 1 – 1, 2 – 2 & DETAILS Submitted on Dated | Ouvrages hydrauliques & génie civil | 31 juil. 2026 | Soumis |
| AFRY.0082.08.304 | POWER HOUSE COMPLEX.SERVICE BAY FLOOR, CONCRETE OUTLINE, SECTION 3 – 3 & DETAILS Submitted on Dated | Ouvrages hydrauliques & génie civil | 31 juil. 2026 | Soumis |
| AFRY.0082.08.305 | POWER HOUSE COMPLEX.SERVICE BAY FLOOR, CONCRETE OUTLINE, SECTION 4 – 4 Submitted on Dated | Ouvrages hydrauliques & génie civil | 31 juil. 2026 | Soumis |
| AFRY.0082.08.306 | POWER HOUSE COMPLEX.SERVICE BAY FLOOR, CONCRETE OUTLINE, SECTION 5 – 5 Submitted on Dated | Ouvrages hydrauliques & génie civil | 31 juil. 2026 | Soumis |
| AFRY.0082.08.307 | POWER HOUSE COMPLEX.SERVICE BAY FLOOR, CONCRETE OUTLINE, SECTION 6 – 6, 7 – 7, 8 – 8 & DETAIL Submitted on Dated | Ouvrages hydrauliques & génie civil | 31 juil. 2026 | Soumis |
| AFRY.0082.09.001 | TAILRACE CHANNEL GENERAL ARRANGEMENT – PLAN | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.002 | TAILRACE CHANNEL GENERAL ARRANGEMENT – LONGITUDINAL SECTION OF TAILRACE CHANNEL ALONG RIGHT BANK | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.003 | TAILRACE CHANNEL GENERAL ARRANGEMENT – LONGITUDINAL SECTION OF TAILRACE CHANNEL ALONG LEFT BANK | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.004 | TAILRACE CHANNEL GENERAL ARRANGEMENT, LONGITUDINAL SECTION OF TAILRACE CHANNEL ALONG CENTER LINE | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.005 | TAILRACE CHANNEL GENERAL ARRANGEMENT, SECTION 1 – 1 & 2 – 2 | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.006 | TAILRACE CHANNEL GENERAL ARRANGEMENT, SECTIONS 3 – 3 TO 7 – 7 | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.007 | TAILRACE CHANNEL GENERAL ARRANGEMENT, SECTION 9 – 9 & 10 – 10 | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.010 | TAILRACE CHANNEL FOUNDATION TREATMENT(SHEAR ZONE AREA) | Ouvrages hydrauliques & génie civil | 17 juil. 2026 | Soumis |
| AFRY.0082.09.101 | TailRace Channel Excavation – Plan & &AIL | Ouvrages hydrauliques & génie civil | — | Soumis |
| AFRY.0082.09.102 | TailRace Channel Excavation – Longitudinal Section Along Right Bank. & &AIL | Ouvrages hydrauliques & génie civil | — | Soumis |
| AFRY.0082.09.103 | TailRace Channel Excavation – Longitudinal Section Along Left Bank. & &AIL | Ouvrages hydrauliques & génie civil | — | Soumis |
| AFRY.0082.09.104 | TailRace Channel Excavation – Cross Sections & &AIL | Ouvrages hydrauliques & génie civil | — | Soumis |
| AFRY.0082.09.105 | TailRace Channel Excavation – Cross Sections & Other Details & &AIL | Ouvrages hydrauliques & génie civil | — | Soumis |
| AFRY.0082.09.301 | TAILRACE CHANNEL, BACKFILL & LEVELING CONCRETE, PLAN & TYPICAL CROSS SECTION | Ouvrages hydrauliques & génie civil | 09 déc. 2025 | Soumis |
| AFRY.0082.09.302 | TAILRACE CHANNEL CONCRETE OUTLINE – PLAN | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.303 | TAILRACE CHANNEL CONCRETE OUTLINE – LONGITUDINAL SECTION OF TAILRACE CHANNEL ALONG RIGHT BANK | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.304 | TAILRACE CHANNEL CONCRETE OUTLINE – LONGITUDINAL SECTION OF TAILRACE CHANNEL ALONG LEFT BANK | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.305 | TAILRACE CHANNEL CONCRETE OUTLINE – LONGITUDINAL SECTION OF TAILRACE CHANNEL ALONG CENTER LINE | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.306 | TAILRACE CHANNEL CONCRETE OUTLINE – TYPICAL CONCRETE LINING DETAIL | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.307 | TAILRACE CHANNEL CONCRETE OUTLINE – TYPICAL CONCRETE LINING & REINFORCEMENT DETAIL | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.308 | TAILRACE CHANNEL CONCRETE OUTLINE – TYPICAL CONCRETE LINING DETAIL | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
| AFRY.0082.09.309 | TAILRACE CHANNEL CONCRETE OUTLINE WEIR – SECTION 8 – 8 & REINFORCEMENT DETAILS | Ouvrages hydrauliques & génie civil | 25 mars 2026 | Soumis |
279 plan(s) affiché(s) sur 279.Extrait du registre officiel « Liste des Plans et études de Conception Soumis » (GKHEP, 21/09/2026). La colonne « approuvé » du registre source est à ce jour vide : tous les plans sont en attente d'approbation.
Cette bibliothèque ne recense que les documents effectivement publiés par le Ministère des Finances, consultables dans leur format d'origine. Elle est enrichie au fil des publications officielles : rapports d'exécution, notes aux investisseurs et documents d'émission y seront ajoutés dès leur parution.
